Somfy Ysia Zigbee 5-Channel Scroll Remote–1871285
SKU: 1871285
SKU: 1871285. The Somfy Ysia Zigbee 5-Channel Scroll Remote delivers precise, incremental control for up to five Zigbee-enabled blinds or devices. Features a scroll wheel, intuitive interface, and up to 4 years of battery life.
Delivery: 5-7 working days
Product Overview
The Somfy Ysia Zigbee 5-Channel Scroll Remote (1871285) is the ultimate solution for users seeking advanced, multi-zone control with precision adjustment. With five independent channels, you can manage up to five individual Zigbee-enabled blinds, curtains, lighting, or groups of devices—all from a single, stylish handset.
A dedicated scroll wheel allows for fine, incremental adjustments, making it ideal for tilting, dimming, or achieving the perfect position for your blinds or lighting. The remote operates on the Zigbee 3.0 protocol, ensuring seamless integration with a wide range of Somfy Zigbee motors and smart home ecosystems. Its slim, modern profile and intuitive button layout blend effortlessly into any interior décor.
Powered by two AAA batteries (included), the Ysia 5-Channel Scroll Remote offers up to four years of autonomy for reliable, maintenance-free operation. The shock- and splash-proof housing ensures durability, while the included wall mount and screw kit provide flexible installation options. Visual LED feedback guides users through setup and operation, whether used standalone or as part of a connected smart home hub.
Whether you’re adding advanced control to your smart home or upgrading your existing setup, the Somfy Ysia Zigbee 5-Channel Scroll Remote delivers powerful, stylish, and user-friendly performance for all your automation needs.
Handsets and Switches
If you are looking for simple radio operated switches or handsets to operate your new or existing blinds, we have a range below. Starting with simple single channel handsets and ranging to more sophisticated multi-channel handsets and timers.
| File Name | Size | Date | |
|---|---|---|---|
| PEP-ecopassport-Ysia-Zigbee-5-Channel-Scroll-Remote.pdfDownload | 432.97 KB | 24/09/2025 | |
| Ysia1-5-Zigbee-Variation-vs4-1-.pdfDownload | 393.02 KB | 24/09/2025 |
- Product Code
- 1871285
- Connection Type
- Zigbee 3.0 Wireless
- Number of Channels
- 5
- Control
- Scroll wheel for incremental adjustment, open/close/‘my’ buttons per channel
- Battery Type
- 2 x AAA (LR3), included
- Battery Voltage
- 1.5 V
- Battery Life
- Up to 4 years
- Dimensions
- 135 mm (L) x 42 mm (W) x 13 mm (H)
- Weight
- 72 g (unwrapped)
- Range
- Up to 50 m (open field)
- Protection Index
- IP 20
- Operating Temperature
- 0°C to 48°C
- Storage Temperature
- -20°C to 60°C
- Color/Finish
- Pure/White
- Material
- Plastic and metal
- Antenna
- Integrated
- Mounting
- Wall bracket and screw kit included
- Compatibility
- Somfy Zigbee motors, Zigbee 3.0 smart home systems (not compatible with RTS or IO)
- Certifications
- CE and international standards
- Unpack the Somfy Ysia Zigbee 5-Channel Scroll Remote and ensure all components are present.
- Insert the two included AAA batteries into the remote.
- Mount the wall bracket using the provided screws or adhesive, if desired.
- Select the desired channel using the channel selector button.
- Pair the remote with your Zigbee-enabled device or smart home hub following the device’s pairing instructions.
- Use the scroll wheel for precise, incremental adjustments, and the open, close, and ‘my’ buttons for standard control on each channel.
- Program the ‘my’ button on each channel to save your preferred position.
- Check the LED feedback for confirmation of successful pairing and operation.
- Replace batteries as needed (up to 4 years of typical use).
How many devices can I control with the Ysia Zigbee 5-Channel Scroll Remote?
You can control up to five individual Zigbee-enabled devices or groups, one per channel.
What is the main advantage of the scroll remote?
The scroll wheel allows for precise, incremental adjustments—ideal for tilting, dimming, or fine-tuning blind positions.
Is this remote compatible with Somfy RTS or IO products?
No, the Ysia Zigbee scroll remote is only compatible with Zigbee 3.0 devices and systems.
What devices can I control with this remote?
Any Somfy Zigbee-enabled blind, curtain, lighting, or compatible smart device.
How do I program the ‘my’ button for each channel?
Move your blind or device to the desired position on the selected channel, then press and hold the ‘my’ button to save it as your favorite.
What is the battery life?
The remote offers up to 4 years of battery life with the included AAA batteries.
Can I mount the remote on the wall?
Yes, a wall bracket and screw kit are included for easy mounting.
What is the wireless range?
The remote has a range of up to 50 meters in open field conditions.
Is the remote durable?
Yes, it features a shock- and splash-proof housing for everyday durability.
